Electronic Turnstile RFID Half Height Turnstile, Access Control
Half Height Turnstile Mechanism 30 Persons/Minute
Model:RNCF10238-5 Half Height Turnstile
RONA RNCF10238-5 Half height turnstile can be compatible with IC
card, ID card, barcode card, and door access control, fingerprint
reading card recognition device used for staff, provide civilized,
orderly access methods; effectively manage the access of staff .
Which widely is used in some high security places, such as prison,
stadium, parking system area , and so on…
Turnstile working condition is adjustable by setting the button on
main control board.
Turnstile use secondly mechanism with shock absorption device and
Turnstile with 60°anti-reverse function.
Anti-collision avoidance function: Before received the open signal,
the turnstile will lock automatically.
When out of power, turnstile will open the gates automatically to
the request the fire alarm.
Automatic Reset Functions: after you swap the card, during the
specific time(the system default is 10s),System will reset in1~60s
when powered off, turnstile will open automatically, powered on
turnstile will close automatically.
Big direction arrow plate to show passage condition.
Turnstile with swiping card memory function.
Through the management computer to realize remote control and
|Housing Material||304 stainless steel|
|Drive motor||DC 24V brush motor|
|Pass Direction||one or bi-directional|
|Arm Driving Force||1kg|
|LED Light||direction indication|
|Working mechanism||24V solenoid valve(German Technology)|
|Working Environment||Indoor and Outdoor|
|Normal Running Life||More than 5million|
|Card Reader area||holder|
|Reset time after break down||RS485|
|Input interface||12V pulse signal with pulse width >100ms, drive current >10mA|
- Nonstandard Program customized.
- LED Counting function.
- Turnstile shape size can do customized.
- Voice Prompt Function.
